Box Muffle Furnace

Technical overview

Designed around the complete thermal process.

Box Muffle Furnace is a HuanYu muffle furnaces system for ceramic firing, calcination, glass annealing, laboratory heat treatment. Published configuration references include 1200 / 1100 °C configurations and Controlled atmosphere. Final selection depends on the material, workload, process window and selected configuration.

Key technical facts

• +Temperature reference: 1200 / 1100 °C configurations
• +Environment reference: Controlled atmosphere
• +Box muffle stove overview: beautifully designed. Great value for money. Ceramic fiber liner, double-layer air-cooling system. The higher temperature is 1200 ℃, and the common temperature is 1100 ℃. Widely used in ceramics, metallurgy, electronics, glass, chemicals, machinery, refractories, new material development, special materials, building materials and other fields of production and experiments. Box-type muffle furnace is easy to operate and programmable, PID self-tuning, automatic heating, automatic heat preservation, automatic cooling, no need to be on duty; alternatively, it can be equipped with a computer-operated electric furnace (starting the electric furnace, stopping the electric furnace, pausing the heating, setting the heating curve, heating curve storage, historical curve and other double-layer furnace shells, the furnace body is exquisitely sprayed, corrosion-resistant, acid-alkali resistant, The isolation between the body and the furnace is air-cooled, and the temperature on the surface of the shell is less than 45 degrees. Energy saving: The furnace material is (The furnace is made of fiber, resistant to high temperature, rapid heat and quenching, and good thermal insulation performance) Fast heating (The heating rate is adjustable from 1 ℃/h to 40 ℃/min) Dual-circuit protection (over temperature, overpressure, overcurrent, segment coupling, power failure, etc.) Silent electronic relay Standard configuration Digital PID controller, can Adjust the heating curve, holding temperature and holding time Over-temperature alarm and power off, leakage protection, reliable operation of side-open furnace doors, easy to load samples, and can be equipped with ventilation ports to operate both sides (or four sides) of the shell structure in an oxygen or inert atmosphere to ensure a highly uniform temperature distribution (protective gas operation as an additional configuration)
