🧩 Product Overview
The P7H Vacuum Hot Pressing Furnace (Graphite) is a large-scale industrial hot press sintering system designed for high-load applications and large-size advanced materials.
This system features a single-chamber structure with high-pressure capability, delivering stable and reliable hot pressing performance for industrial production.
The system integrates:
- Graphite heating system (induction-based)
- High-load hydraulic pressing system
- Vacuum or controlled atmosphere
👉 Enabling:
- Large-size material densification
- High-pressure sintering
- Stable and repeatable production
Vacuum hot pressing enables particle bonding, grain growth, and pore reduction under high temperature and pressure, forming dense polycrystalline materials
⚙️ Core Applications
This furnace is widely used in:
- Advanced ceramics (SiC, BN, B₄C)
- Cemented carbide materials
- Powder metallurgy
- Carbon and graphite materials
- Composite materials
👉 Typical applications:
- Large ceramic components
- High-load structural parts
- Aerospace and defense materials
🔬 Working Principle (Vacuum Hot Pressing)
The system operates using high temperature and uniaxial pressure under vacuum conditions:
- Powder is loaded into graphite molds
- Vacuum or inert gas atmosphere is applied
- Graphite heating raises temperature
- Hydraulic system applies pressure
- Material densifies into a solid structure
👉 Result:
- Reduced porosity
- Increased density
- Uniform microstructure
⭐ Key Features & Advantages
✔ Large-Scale Single-Chamber Design (Core Advantage)
- Designed for large components and heavy loads
- Simple and stable structure
👉 Ideal for industrial batch production
✔ Fast Heating Performance
- Heating rate:
- 20°C/min (<1600°C)
- 10°C/min (>1600°C)
✔ Excellent Temperature Uniformity
- Temperature uniformity: ±5°C
- Multi-point temperature monitoring
✔ High Pressure Capability
- Maximum pressure:
- ≤6000 kN (P7 level)
✔ High Pressure Accuracy
- Hydraulic control system
- Pressure accuracy: ±3%
✔ Advanced Thermal Field Design
- Optimized heating chamber
- Modular insulation system
✔ High Degree of Automation
- PLC + HMI + PID control
- Fully automated process (except loading/unloading)
✔ Reliable Sealing Performance
- Corrugated pipe sealing structure
- Ensures vacuum integrity
✔ High Safety Performance
- Integrated pressure sensing and control
- Stable and reliable operation
📊 Technical Specifications (Strictly Based on Product Data)
| Parameter | Value |
|---|---|
| Chamber Size | Φ700 × 700 mm |
| Sample Diameter | ≤420 mm |
| Max Pressure | ≤6000 kN |
| Stroke | 350 mm |
| Vacuum Level | ≤5 Pa / 6.7×10⁻³ Pa |
| Max Temperature | 2200°C |
| Max Mold Diameter | ≤450 mm |
📌 All specifications are strictly aligned with official product data
🏭 Application Fields
This system is ideal for:
- Industrial production lines
- Large-scale material manufacturing
- Aerospace and defense industries
- High-performance ceramic and composite production
👉 Especially suitable for:
- Large ceramic parts
- High-load structural materials
- Industrial batch production
🚀 Why Choose P7H Furnace?
👉 Best for Large Components
- Designed for large diameter and high load
👉 Best for Stable Production
- Single-chamber structure ensures reliability
👉 Best for Cost Efficiency
- Lower complexity than dual-chamber systems
⚖️ P5H vs P7H vs P7V
| Feature | P5H | P7H | P7V |
|---|---|---|---|
| Scale | Medium | Large | Large |
| Structure | Single chamber | Single chamber | Dual chamber |
| Pressure | ≤3000 kN | ≤6000 kN | ≤6000 kN |
| Capacity | Medium | Large | Large |
| Efficiency | Medium | Medium | High |
| Application | Standard production | Large parts | High-throughput production |
👉 Recommendation:
- Standard production → P5H
- Large components → P7H
- High-efficiency production → P7V
🧩 Customization Options
- Chamber size customization
- Pressure system upgrade
- Thermal field optimization
- Automation system integration
🎯 Why Choose Us?
- Professional vacuum hot pressing furnace manufacturer
- Complete P series product range (P2–P7 + continuous systems)
- Strong expertise in high-temperature sintering technology
- Reliable technical and after-sales support
📩 Get a Quote
Looking for a reliable large-scale vacuum hot pressing furnace supplier?
Contact us today for customized solutions and quotation.
