Atmosphere Tube Furnace

Technical overview

Designed around the complete thermal process.

Atmosphere Tube Furnace is a HuanYu tube furnaces system for controlled-atmosphere heating, vacuum heat treatment, powder processing, CVD research. Published configuration references include Configuration specific and Controlled atmosphere. Final selection depends on the material, workload, process window and selected configuration.

Key technical facts

• +Temperature reference: Configuration specific
• +Environment reference: Controlled atmosphere
• +Tubular furnaces are mainly used in metallurgy, glass, heat treatment, lithium battery positive and negative materials, new energy, led luminous materials, abrasives and other industries to determine the equipment specifications under atmospheric conditions: Installation: The installation of the furnace body Tubular atmosphere furnace can be placed on the workbench to suit the physiological operation height of the human body, and the bearing of the workbench should be greater than 200kg. Electrical installation power supply configuration: 220V. The power configured according to the user's electronic control cabinet should be greater than 6Kw. The thermocouple is inserted into the furnace depth of 25mm, and the N index number compensation wire is used to connect with the temperature control instrument. Note: The quartz tube should be installed first and then the thermocouple should be installed. The thermocouple should not be in contact with the quartz tube. The electric furnace and control cabinet shall be grounded as a whole, and the grounding resistance of the grounding wire shall be less than 4Ω. Resistance wire wiring mode: two parallel connections, power supply: single-phase 220V. At the same time, due to transportation and other reasons, the tightening of the screws of the furnace body should be checked and confirmed to be correct.
